Specification
01. PCB Size: MAX:500×350(400)mm (MIN:100×80mm)
02. PCB Flow Direction: Left → Right
03. PCB Positioning Method: Vision System
04. X.Y Placement Accuracy: 0.05mm @ 3 Sigma
05. X.Y Axis Repeat Ability: 0.02mm @ 3 Sigma
06. X.Y Axis Speed: 500mm/sec
07. Transport Height: 900±20mm
08. Control System: X-Y-Z 3 axes AC servomotor
09. Operating System: Microsoft Windows
10. Dot Placement Performance: Max.14400 DPH
11. Power Requirements: Single phase AC 220V 50/60Hz 1KW
12. Air Supply Requirements: 4-6 kg/cm² Consuming:0.3m³/min
13. Machine size (W×D×H): 1350×1200×1650mm
14. Machine Weight: 800 kg
